| Name | Unit | Parameter | Remarks |
| Work Table Size | mm | 2012×1200 | |
| X/Y/Z-axis Travel | mm | 2000×1200×150 | (X-axis;Y-axis;Z-axis respectively) |
| Table Load Capacity | kg | 200 | |
| X/Y-plane Roundness Error | mm | 0.015 | Measured within a 300mm diameter range |
| Positioning Accuracy | mm | 0.008 (VDI-3441) | |
| Repeat Positioning Accuracy | mm | 0.004 (VDI-3441) | |
| Tool Setting Accuracy | mm | <0.01 | |
| Max Travel Speed | mm/min | 15,000 | |
| Max Machining Speed | mm/min | 9,000 | |
| Machine Weight | kg | 8,400 | |
| Air Pressure Requirement | 0.55-0.65 MPa;0.10m³/min | Positive pressure | |
| Vacuum Pressure | -0.06 MPa Negative pressure | Requirement | |
| Power Supply | AC 380V,50Hz | ||
| Machine Lubricant | Solid Guideway Grease | Regular replenishment required | |
| Workpiece Cooling | Water Cooling | ||
| Electrical Cabinet Cooling | Condenser System | ||
| Operating Environment | Temperature:0-45℃; Humidity:30-75%RH | ||
| Water Consumption | L/min | 30-45 | Single-machine circulation (adjustable flow rate) |
| Vacuum Drainage System | Set | Compatible With Yongxing HYX-G01 |
